Mechanical bench scale with weighing dial – Loading platform 600×650 mm – Lever mechanism steel AQ42 – Knives and steel bearings Ni-Cr-Mo with hardness 63-65 HRC – Oscillation index adjustable – Shock Oil oscillation adjustable – oven painted with epoxy enamel – Clock diam. 570 mm.
- Industrial Weighing Systems
- +39 0331 219156
841
841
at
| Cod. | Dimensions - mm | Capacity - kg | Division - g |
| 841 - 50 | 600×650 | 50 | 50 |
| 841 - 60 | 600×650 | 60 | 20 |
| 841 - 80 | 600×650 | 80 | 20 |
| 841 - 100 | 600×650 | 100 | 50 |
| 841 - 150 | 600×650 | 150 | 50 |
| 841 - 200 | 600×650 | 200 | 50 |
Mod. 841
Options and Accessories
| Description |
| Painted trolley with wheels |
| Stainless steel AISI304 trolley with wheels |
| ZampPainted steel legs with wheels ( h. mm 600 ) |
| Stainless steel legs with wheels ( h. mm 600 ) |
| AISI304 stainless steel platform |
| AISI304 stainless steel bank |
| AISI304 Stainless steel platform with three banks |
| Zinc plated levers |
| Stainless steel levers |
| Stainless steel knives and bearings |
| Stainless steel external structure |
| Double reading dial |
Documents
User Manual
